Gas Detector
Gas-Max
Zone Zone 0/20
Sensors Multi (4)
Protection IP67
Battery 1300 mAh
A rugged portable multi gas detector with a compact and affordable design meant to withstand harsh environments. Developed with a User-Centered Design Process to make the device interface and handling...
Key Features
INTRINSICALLY SAFE
Explosion Proof / ATEX Zone 0/20
ALARMS
Light, Sound, Vibration
ULTRA-RUGGED
IP67
SENSORS
Hosts up to 4 sensors (CO, H2S, Methane, O2, etc.)
HUMIDITY
10%-95% RH (no condensation)
BATTERY
1300 mAh (Rechargable)
Technical Specifications
Battery1300 mAh
DisplayTFT Color LCD Screen
Warranty2 Years
Sensor TypeElectrochemical, Catalytic
Sensor RangeMethane (0-100%LEL), O2 (0-30%VOL), H2S (0-100 ppm), CO (0-500 ppm), etc.
IP ProtectionIP 67
Response TimeT90 < 30S
Humidity Range10%-95% RH
Sampling MethodDiffusion
Interested in Gas-Max?
Our technical experts can provide detailed product specifications, pricing, and integration support tailored to your hazardous area requirements.
